| 产地 | 马鞍山 |
|---|---|
| 产品认证 | IOS9001 |
| 动力类型 | 液压 |
| 规格 | 锻压 |
| 重量 | 6.7T |
| 剪切次数 | 10（次/min） |
| 品牌 | 茂利丰 |
| 型号 | QC12Y-6X4000 |
| 加工定制 | 是 |
| 可加工尺寸 | 6*4000（mm） |
产品性能及特点及参数：
1.采用钢板焊接结构，液压传动，蓄能器回程，操作方便，性能可靠，外形美观。
2.刃口间隙調整有指示牌指示，調整轻便迅速。
3.设有灯光对线裝置，并能无級调节上刀架的行程量。
4.采用栅栏式人身安全保护裝置。
5.后挡料尺寸及剪切次数有数字示裝置。
技术参数：
| 型号 | 可剪板厚mm | 可剪板宽mm | 剪切角度 | 喉口深度mm | 后挡料行程mm | 行程次数/min | 电机功率kw | 外形尺寸mm |
| 4x2500 | 4 | 2500 | 1.5 | 100 | 20-500 | 18 | 5.5 | 3200x1600x1600 |
| 4x3200 | 4 | 3200 | 1.5 | 100 | 20-500 | 15 | 5.5 | 3900x1600x1600 |
| 4x4000 | 4 | 4000 | 1.5 | 100 | 20-600 | 12 | 7.5 | 4700x1600x1600 |
| 4x5000 | 4 | 5000 | 1.5 | 100 | 20-600 | 12 | 11 | 5800x1750x1850 |
| 4x6000 | 4 | 6000 | 1.5 | 100 | 20-600 | 8 | 11 | 6800x1750x1850 |
| 6x2500 | 6 | 2500 | 1.5 | 100 | 20-600 | 15 | 7.5 | 3200x1650x1800 |
| 6x3200 | 6 | 3200 | 1.5 | 100 | 20-600 | 12 | 7.5 | 3900x1650x1800 |
| 6x4000 | 6 | 4000 | 1.5 | 100 | 20-600 | 10 | 7.5 | 4700x1650x1800 |
| 6x5000 | 6 | 5000 | 1.5 | 100 | 20-600 | 10 | 11 | 5800x1800x1950 |
| 6x6000 | 6 | 6000 | 2 | 100 | 20-600 | 8 | 11 | 6800x1800x1950 |
| 8x2500 | 8 | 2500 | 2 | 100 | 20-600 | 16 | 7.5 | 3200x1700x1850 |
| 8x3200 | 8 | 3200 | 2 | 100 | 20-600 | 14 | 7.5 | 3900x1700x1850 |
| 8x4000 | 8 | 4000 | 2 | 100 | 20-600 | 11 | 7.5 | 4700x1700x1850 |
| 8x5000 | 8 | 5000 | 2 | 100 | 20-600 | 10 | 11 | 5800x1900x2100 |
| 8x6000 | 8 | 6000 | 2 | 120 | 20-600 | 8 | 11 | 6900x1900x2200 |
| 10x2500 | 10 | 2500 | 2 | 120 | 20-600 | 12 | 11 | 3200x1850x1900 |
| 10x3200 | 10 | 3200 | 2 | 120 | 20-600 | 10 | 11 | 3900x1850x1900 |
| 10x4000 | 10 | 4000 | 2 | 120 | 20-600 | 8 | 18.5 | 4700x1850x1900 |
| 10x5000 | 10 | 5000 | 2 | 120 | 20-600 | 7 | 18.5 | 5800x2000x2150 |
| 10x6000 | 10 | 6000 | 2 | 120 | 20-600 | 6 | 18.5 | 6800x2000x2500 |
| 12x2500 | 12 | 2500 | 2.5 | 120 | 20-600 | 11 | 18.5 | 3200x2050x2150 |
| 12x3200 | 12 | 3200 | 2.5 | 120 | 20-600 | 10 | 18.5 | 3900x2050x2150 |
| 12x4000 | 12 | 4000 | 2.5 | 120 | 20-600 | 8 | 18.5 | 4700x2050x2150 |
| 12x5000 | 12 | 5000 | 2.5 | 120 | 20-600 | 7 | 22 | 5800x2200x2200 |
| 12x6000 | 12 | 6000 | 2.5 | 120 | 20-600 | 6 | 22 | 6800x2400x2600 |
| 16x2500 | 16 | 2500 | 2.5 | 120 | 20-600 | 10 | 18.5 | 3200x2150x2250 |
| 16x3200 | 16 | 3200 | 2.5 | 120 | 20-600 | 9 | 18.5 | 3900x2150x2250 |
| 16x4000 | 16 | 4000 | 2.5 | 120 | 20-600 | 8 | 22 | 4700x2150x2250 |
| 16x5000 | 16 | 5000 | 2.5 | 120 | 20-600 | 6 | 30 | 5800x2500x2500 |
| 16x6000 | 16 | 6000 | 2.5 | 120 | 20-600 | 6 | 37 | 6800x2500x2700 |
| 20x2500 | 20 | 2500 | 3 | 120 | 20-600 | 8 | 22 | 3200x2250x2350 |
| 20x3200 | 20 | 3200 | 3 | 120 | 20-600 | 7 | 22 | 3900x2250x2350 |
